PP Ball Valve Screw End Manufacturer, Supplier & Exporter
The offered range of the ball valve is used to regulate the flow of the different types of fluid with the utmost precision. The offered valves are equipped with the screw end in order to make it best fit with the varying prerequisite of the end users. The defined manufacturing processes make this range of the PP ball valve screw end completely leak free experience, which one can profit in the different specifications as per their requirements.
| TECHNICAL SPECIFICATION FOR PP Ball Valve Screw End | |
| Material Of Construction | PP (Polypropylene), PVDF (Polyvinylidene fluoride) |
| Design | 3 piece design |
| Maximum working temp | 80 c (consistently) |
| Connection End | Screw end (BSP thread) |
| Construction | 3 piece design, 1 piece stem (spindle), full bore, Teflon seated |
| Hydraulic Test Pressure | Body-150 PSI & SEAT-100 PSI |
| Size Range | ½”- 15MM TO 100MM- 4” |
| Standard | As per manufactuer’s |
